Numerical analysis of plastic damage of concrete cutoff wall for concrete face rockfill dam

WEN Lifeng，LI Yanlong，CHAI Junrui
（State Key Laboratory of Eco-hydraulics in Northwest Arid Region，Xi’an University of Technology，Xi’an 710048，China）

Abstract：Under the action of dam filling and reservoir impoundment，the working and stress conditions of
the cutoff wall are complicated，which may cause plastic strain and wall cracking. This paper combines the
measured data and numerical analysis to study the stress， deformation and damage behaviour of the cutoff
wall of a concrete faced rockfill dam. Based on the analysis of the stress and deformation characteristics of
the cutoff wall on the basis of measured data，the plastic damage model of concrete is used to establish a
three-dimensional numerical model for the mechanical behaviour of the cutoff wall. The numerical model
considers seepage-stress coupling effect of the dam and foundation and the contact effect between the cutoff
wall and the overburden， and truly simulates the process of dam filling and reservoir storage. The numeri⁃
cal calculation model is verified by the measurement data. The force mechanism and its stress deformation
and damage cracking characteristics are deeply analyzed combining with the measurement data and numeri⁃
cal results. The effect of the seepage-stress coupling effect of the dam and foundation， wall position， and
wall material on the mechanical behaviour of the cutoff wall is discussed. The research results have guiding
significance for the construction and structural safety control of cutoff walls of concrete face rockfill dams.
Keywords： concrete cutoff wall； stress and deformation； damage characteristics； numerical analysis； influ⁃
encing factors
